distance (bluetooth) parking management system jy-t30
apply to: a fixed vehicle-based senior executive channels, high-end residential, clubs, apartments, villas, enterprises and institutions.
dimensions: 100x260x1380
basic features: long-distance non-stop reader gate, vehicle and auto-closing.
economy: cheap, unattended, and easy maintenance.
reliability: 2.4g bluetooth communication protocol, sleep wake patterns reflect, when the vehicle was started near the bluetooth signal range reader, card reader accurately, to engage in strong interference.
scalability: you can upgrade the software version, additional management center, easy to manage and query.
reading distance: 5m-15m adjustable, non-stop reader, to improve access speed, full owner noble status.
system description:
1 optical excitation, cdma, sleep wake, bluetooth communication, cpu automatically identify high-tech crystal.
(2) speed reader, reader distance, with good direction, reading distance can be controlled, 10-40 kilometers per hour non-stop reader gate.
3 can penetrate car protection film (such as explosion-proof membrane) is not affected, apply to all vehicles.
4 do not stop, do not drive windows reader; bad weather snow storm reader from the vehicle impact.
5 non-stop reader, to improve traffic flow, traffic jams are no longer the peak of the phenomenon of long lines, you save fuel.
6 no interference between readers (the use of advanced communication technology and cdma bluetooth technology, cpu automatic identification), the direction is good, valid vehicle around each other to solve interference problems.
available colors: yellow, orange (non-standard order)
technical parameters:
operating temperature: -30 ℃ ~ 75 ℃;
humidity:: ≤ 95% non-condensing
bluetooth card reader time: ≤ 0.1s
bluetooth card reader from :2-15m (adjustable)
power supply voltage: ac220v ± 10% 50hz;
power: 100w;
communication: rs485/232 tcp / ip can-bus;
communication distance: 1200m (rs485/422);
off-line storage capacity: 20,000 (expandable);
black capacity: 10,000 (expandable);
data transmission speed: 4800bps/100m
