standard parking management system jy-t40
for: high-end residential, public parking, shopping malls, large office buildings and other temporary vehicle fees need to set more places.
dimensions: 300x450x1330
function characteristics:
1, completely modular design, relatively independent of each subsystem, system integration is high.
2, the configuration of high-brightness led display in english, intelligent voice prompts.
3, intelligent control board can control the number of readers: a close, a long distance.
4, access control machine on display a variety of information can be released as needed.
5, intelligent voice control system, using the asd company dedicated highly integrated voice chip design, flexible playback of voice.
6, can realize remote control, check, digital connectivity.
7, a card, a car, card issuing system with interlock to ensure that vehicles are issuing to prevent charging holes.
8, entrance automatically capture the image, adjust the image when played comparison, all images are saved automatically.
9, chinese, english, management software, using c / s structure, sql2000 back-end database.
10, the system uses two control modes offline and online.
11, intercom features, user and management personnel.
12, automatic card handling, easy to manage temporary user card.
economy: the use of recycled card, cost, 485-bus transmission system, maintenance is simple.
compatibility: optional id and ic cards, card readers and other facilities can be composed of card system.
security: management software with a variety of management rights, confidentiality is high; can be set free cards, monthly cards and a variety of temporary charge card, diversity management vehicles; image contrast capabilities, access to records and powerful real-time vehicle information query functions, vehicles to prevent illegal release and loss situation.
scalability: network edition can be upgraded to achieve more and more into network management.
reading distance: 2cm-5cm.
available colors: yellow, orange (non-standard order)
technical parameters:
operating temperature: -30 ℃ ~ 75 ℃;
humidity: ≤ 95% non-condensing;
ic card reader time: ≤ 0.1s;
ic card reader distance: ≤ 10cm;
power supply voltage: ac220v ± 10% 50hz;
power: ≤ 100w;
communication: rs485/232 tcp / ip can-bus;
communication distance: 1200m (rs485/422);
off-line storage capacity: 20,000 (expandable);
black capacity: 10,000 (expandable);
data transmission speed: 4800bps/100m
